AL8XGTE-3 OKOS 高速数据采集器

AL8XGTE-3 是一款高速数据采集卡，专为 PCI Express x1 总线设计。它主要用于高速瞬态捕获，并具备一系列强大的功能特性。

首先，AL8XGTE-3 提供了多种采样率选择，包括 1、1.5、2 或 3 GSsamples/s，确保了极高的采样速度。这种高速采样能力使得它能够捕获快速变化的信号，从而满足各种应用需求。

其次，该数据采集卡配备了大型双端口板载缓冲存储器，允许同时进行瞬态记录和读出捕获的数据。这种设计确保了数据采集的连续性和高效性，避免了数据丢失或延迟。

此外，AL8XGTE-3 还具有后处理部分，可用于提取多个门的峰值信息。这对于信号处理和分析非常有用，可以帮助用户更好地理解和利用采集到的数据。

值得一提的是，AL8XGTE-3 采用了直流耦合的模拟输入，并以 50 欧姆阻抗端接。这种设计可以在超过 1 GHz 的整个模拟带宽内实现高信号保真度。这意味着即使在高频下，数据采集卡也能保持信号的准确性和真实性。

在数据传输方面，AL8XGTE-3 通过 PCI Express 总线将采样数据传输到 PC 的主存储器中。这种传输方式具有高速和高效的特点，可以确保数据及时、准确地传输到计算机进行进一步处理。

另外，AL8XGTE-3 还具有两个分辨率为 8 位的 A/D 转换器，可以以 1.0 或 1.5 Gsamples/s 的速度对输入信号进行采样。同时，它还支持两个 A/D 转换器的板级版本，可以同时对两个输入通道进行采样，或者在一个通道上以交错方式使用两个 A/D 转换器，以实现 2.0 或 3.0 Gsamples/s 的有效采样率。

总之，AL8XGTE-3 是一款功能强大、性能卓越的高速数据采集卡。它具备高速采样、大容量缓冲存储器、高信号保真度、高效数据传输等特点，适用于各种需要高速瞬态捕获的应用场景。无论是科学研究、工程测试还是工业生产等领域，AL8XGTE-3 都能提供可靠的数据采集解决方案。

The AL8XGTE-3 is a high-speed data acquisition card designed for the PCI Express x1 bus. It is mainly used for high-speed transient capture and has a series of powerful functional features.

First, the AL8XGTE-3 offers a variety of sampling rate options, including 1, 1.5, 2 or 3 GSsamples/s, ensuring extremely high sampling speeds. This high-speed sampling capability enables it to capture rapidly changing signals to meet a variety of application requirements.

Second, the data acquisition card is equipped with a large dual-port onboard buffer memory that allows simultaneous transient recording and readout of the captured data. This design ensures continuity and efficiency of data acquisition and avoids data loss or delay.

In addition, the AL8XGTE-3 has a post-processing section that can be used to extract peak information from multiple gates. This is very useful for signal processing and analysis, helping users to better understand and utilize the collected data.

It is worth mentioning that the AL8XGTE-3 uses a DC-coupled analog input and is terminated with a 50 ohm impedance. This design enables high signal fidelity over the entire analog bandwidth of more than 1 GHz. This means that even at high frequencies, the data acquisition card can maintain the accuracy and authenticity of the signal.

In terms of data transfer, the AL8XGTE-3 transmits sampled data to the PC's main memory via the PCI Express bus. This transmission method has the characteristics of high speed and efficiency, which can ensure that the data is timely and accurately transmitted to the computer for further processing.

In addition, the AL8XGTE-3 has two 8-bit resolution A/D converters that can sample input signals at 1.0 or 1.5 Gsamples/s. It also supports board-level versions of two A/D converters that can sample both input channels at the same time, or use two A/D converters interleaved on one channel to achieve an effective sampling rate of 2.0 or 3.0 Gsamples/s.

In short, the AL8XGTE-3 is a powerful, high-performance high-speed data acquisition card. It has the characteristics of high-speed sampling, large capacity buffer memory, high signal fidelity, efficient data transmission, etc., and is suitable for various application scenarios requiring high-speed transient capture. Whether in scientific research, engineering testing or industrial production, the AL8XGTE-3 provides reliable data acquisition solutions.
