4104C ZYGO 位移测量干涉仪

位移测量干涉仪是一种利用干涉原理进行位移测量的高精度仪器。4104C通常由激光源、干涉仪、探测器和数据处理系统组成。激光源发出激光束，经过干涉仪后分成两路或多路，再经过反射镜或其他光学元件后重新汇合，形成干涉条纹。当被测物体发生位移时，干涉条纹也会发生变化，通过探测器检测干涉条纹的变化，可以测量出被测物体的位移量。

位移测量干涉仪具有高精度、高分辨率、高灵敏度等优点，因此被广泛应用于各种需要高精度位移测量的领域，如光学、机械、航空、航天等领域。其中，激光干涉仪是位移测量干涉仪的一种，4104C利用激光的高单色性、高相干性和高亮度等特点，可以实现更高的测量精度和稳定性。

除了测量位移外，位移测量干涉仪还可以用于测量其他物理量，如角度、振动、表面形貌等。同时，随着技术的不断发展，位移测量干涉仪的性能和功能也在不断提升，如出现了基于光纤的位移测量干涉仪、多轴位移测量干涉仪等新型仪器，为各种复杂测量任务提供了更加灵活和高效的解决方案。

需要注意的是，位移测量干涉仪的使用需要一定的专业知识和技能，正确的操作和维护对于保证测量精度和仪器寿命至关重要。因此，在使用位移测量干涉仪时，需要遵循相关的操作规范和安全规定，并进行定期的校准和维护。

Displacement measurement interferometer is a kind of high precision instrument for displacement measurement based on interference principle. 4104C usually consists of a laser source, interferometer, detector and data processing system. The laser beam emitted by the laser source is divided into two or more paths after the interferometer, and then rejoined after the reflector or other optical elements to form an interference fringe. When the measured object is displaced, the interference fringe will also change. By detecting the change of the interference fringe, the displacement of the measured object can be measured.

Displacement measurement interferometer has the advantages of high precision, high resolution and high sensitivity, so it is widely used in various fields requiring high precision displacement measurement, such as optics, machinery, aviation, aerospace and other fields. Among them, the laser interferometer is a kind of displacement measurement interferometer, 4104C can achieve higher measurement accuracy and stability by using the characteristics of high monochromism, high coherence and high brightness of laser.

In addition to measuring displacement, displacement measurement interferometers can also be used to measure other physical quantities, such as Angle, vibration, surface topography, etc. At the same time, with the continuous development of technology, the performance and function of displacement measurement interferometers are also constantly improving, such as the emergence of new instruments based on optical fiber displacement measurement interferometers, multi-axis displacement measurement interferometers and other instruments, providing a more flexible and efficient solution for various complex measurement tasks.

It should be noted that the use of displacement measurement interferometers requires a certain amount of professional knowledge and skills, and correct operation and maintenance is crucial to ensure measurement accuracy and instrument life. Therefore, when using the displacement measurement interferometer, it is necessary to follow the relevant operating specifications and safety regulations, and carry out regular calibration and maintenance.
